Item No. S720-16SR02G08GIND

16 Channel Digital Output Module

1 of 3

General Information +

No. of Digital Outputs	16 Channels
Hardware Functional Status	From July 22
Firmware Version	1.00.001
Firmware Update Possible	Yes
Engineering Software	CODESYS V3.5 SP19 and above
Mounting	Base Unit TBUS-PPPPPPPP

Isolation +

Galvanic Isolation	Yes
Galvanic Isolation Group	2
Channels In Group	8

Mode Of Operation +

DO	Yes
DO With Energy Saving Function	No
PWM	No

Power Supply +

Power Supply From	Top Side De-Coded Plug-In Screw Terminal
Normal Supply Voltage	24 V DC
Low Supply Voltage	18.5 V DC
High Supply Voltage	28.5
Reverse Polarity Protection	Yes
Maximum Current	100 mA
Power Loss	Less than 1 W (Typical 0.75W)

Hardware Configuration +

Automatic Encoding	No
Mechanical Coding Element	Yes

Digital Output +

Number Of Digital Inputs	16 Channels
Type Of Digital Outputs	Source Output
Current Sinking	No
Current Sourcing	Yes
Digital Input Parameterizable	Yes
Short-Circuit Protection	Yes
Response Threshold	1 A
Open Circuit Detection	Yes
Controlling a Digital Output	Yes
Switching Capacity To Resistive Load	0.5 A

Output Current +

For "1" Signal	0.5 A
For "1" Signal	0.1 mA

Delay In Output with Resistive Load +

From 0 To 1	Max 50 µs
From 1 To 0	Max 100 µs

Parallel Switching Of Two Outputs +

Uprating	No
Redundant Control Of Load	Yes (with suitable FTA)

Total Current +

Per Channels	0.5 A
Per Module	08 A

Module Current as Horizontal Installation +

30 Degree Celsius	8 A
40 Degree Celsius	7 A
50 Degree Celsius	6 A
60 Degree Celsius	4 A

Module Current as Vertical Installation +

30 Degree Celsius	8 A
40 Degree Celsius	6 A
50 Degree Celsius	4 A

Diagnostic +

Function Of Diagnostic	Yes
Diagnostic Alarm	Available

Diagnostic Messages +

Diagnostic Info Readable	Yes
Supply Voltage Monitoring	Yes
Group Error	Yes

LED +

Power of Indication	Yes
Channels Status	Yes
Module Fuse Blown	No
Module Diagnostics (Back-Plane comm)	Yes

Potential Separation +

Separation Between Channels	Yes
Separation Between Backplane	Yes
Separation Between Channels And System Power Supply	Yes
Insulation Tested With	500 V DC

Ambient Condition +

Horizontal Installation	0°C
Horizontal Installation	60°C
Vertical Installation	0°C
Vertical Installation	60°C

Connection +

Field Connection	37-Pin D-Sub Female Connector
Power Connection	5 Pin Phoenix Plug-In Screw Connector (De-Coded)

Other Information +

Cable Length Max.	500 M
Address Space Per Module	2 Bytes
Dimensions (W x H x D)	25 x 122 x 115 MM
Weight	145g Approx

The Digital Output module is an essential component of any PLC system, transforming Digital Input signals into crucial Digital Output signals. These outputs are integral for controlling actuators, motors, lights, alarms, and other devices that require external control. All guided by sophisticated logic sequences built in the PLC’s. By choosing the right Digital Output module, you ensure not only maximum performance and accuracy but also unmatched stability and safety throughout your industrial automation projects. Our digital output modules, featuring 16 channels galvanically isolated into 2 distinct groups of 8 channels each, provide unparalleled reliability and efficiency, making them the ideal choice for your automation needs.
